Welded Stainless Steel Seamless Pipe Tube 304 304L 316 316L 904L

Name: Welded Stainless Steel Seamless Pipe Tube 304 304L 316 316L 904L
Brand: MITTEL TISCO BAO STEEL
Price: 6.5 USD

Brand Name : MITTEL TISCO BAO STEEL

Model Number : 904L

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 300KGS

Price : 6.5 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 50000KGS

Delivery Time : 7 Days

Packaging Details : Wooden Box

Application : Construction,Industry,boiler,Chemical

Standard : DIN,ASTM,JIS,AISI

Type : Seamless

Welding line type : Seamless

Thickness : 0.5 ~ 60mm

Length : 3000mm~6000mm,Customer Request

Shape : Round Pipe Tube

Outer diameter : 6-630mm

Technique : Cold Drawn

Surface : Annealing,pickling

Contact Now

Welded Stainless Steel Pipe 304 304L 316 316L 904L Stainless Steel Tube

Seamless stainless steel round pipe, also known as stainless steel seamless pipe, is made of steel ingot or solid pipe blank through perforation to make a capillary, and then by hot rolling, cold rolling or cold dialing. The specifications of seamless steel pipes are expressed in millimeters of outer diameter * wall thickness.

904L has high nickel composition with low carbon content, copper alloy adding improve its resistance to corrosion, the “L” in 904L stands for low carbon, it is typical Super Austenitic stainless steel, equivalent grades are DIN 1.4539 and UNS N08904, 904L has better properties than other austenitic stainless steels.

Specification

Standard	API, ASTM, BS, DIN, GB, JIS
Outer Dia:	21.3mm-660mm
Wall Thickness	0.5mm-20mm
Dia Tolerance	Control with in the standard, OD:+-1%, WT:+-10%
Materials	10#,20#,45#,Q235,Q345,Q195,Q215,Q345C,Q345A
	ASTM A53A/A53B/ A178C/A106B API5L
	ST37,ST37-2,DIN 1629 ST35, ST45,DIN 17175 ST35.8,DIN 17175 19Mn5
	16Mn,Q345B,T1,T2,T5,T9,T11,T12,T22,T91,T92,P1,P2,P5,P9,P11,P12,P22,P91,P92,15CrMO, Cr5Mo,10CrMo910,12CrMo,13CrMo44,30CrMo,A333 GR.1,GR.3,GR.6,GR.7
	Gr.B,X42,X46,X52,X60,X65,X70,X80,X100
Inspection	ISO,BV,SGS,MTC
Packing	Steel strip packed. Standard Export Seaworthy Package.Suit forall kinds of transport,or as required
Application	Widely used in Structure, Accessorize,Construction, Fluid transportation,machinery parts,the stress parts of the automobile tractor parts and so on
MOQ	5metric ton,sample order accepted
Shipment time	Within 7-10 workdays after receiving deposit or L/C

904L Stainless Steel Chemical Composition (Max %):

Grade	Ni	Cr	Mo	Cu	C	Mn	Si	P	S	Fe
904L	23 – 28	19 – 23	4 -5	1 – 2	0.02	2	1	0.045	0.035	Balance

904L Stainless Steel Mechanical Properties

Grade	Tensile Strength, Min	Yeild Strength, Min	Elognation	Hardness
904L	490 Mpa	215 Mpa	35%	90 HRB Max

904L Stainless Steel Physical Properties

Grade	Density (Kg/M3)	Elastic Modulus (GPa)	Mean Co-Eff Of Thermal Expansion (Μm/M/°C)			Thermal Conductivity (W/M.K)		Specific Heat 0-100°C (J/Kg.K)	Elec Resistivity (NΩ.M)
Grade	Density (Kg/M3)	Elastic Modulus (GPa)	0-100°C	0-315°C	0-538°C	At 20°C	At 500°C	Specific Heat 0-100°C (J/Kg.K)	Elec Resistivity (NΩ.M)
904L	7900	190	15	–	–	11.5	–	500	952

904L Stainless Steel Properties

Excellent resistance to stress corrosion cracking due to the presence of high amounts of nickel content.
Pitting and crevice corrosion, intergranular corrosion resistance.
Grade 904L is less resistant to nitric acid.
Excellent formability, toughness and weldability, due to low carbon composition, it can be welded using any standard method, 904L cannot be hardened by heat treatment.
Non-magnetic, 904L is an Austenitic stainless steel, therefor 904L possesses Austenitic structure properties.
Heat Resistance, Grade 904L stainless steels offer good oxidation resistance. However, the structural stability of this grade collapses at high temperatures, particularly above 400°C.
Heat Treatment, Grade 904L stainless steels can be solution heat-treated at 1090 to 1175°C, following by rapid cooling. Thermal treatment is suitable for hardening these grades.

904L Stainless Steel Equivalents

WERKSTOFF NR 1.4539
UNS N08904
BS 904S13

SMLS Pipe 904L A312 45 mm x 5 mm UNS N08904 Stainless Steel Seamless Tube
